ScrollDelay

Systems · Delay · Delayed systems

Dimension: 1

Equations

\[ \begin{aligned} \dot{y_{0}} &= - \alpha y_{0}{\left(t - \tau \right)} + \beta \tanh{\left(10 y_{0}{\left(t - \tau \right)} \right)} \end{aligned} \]

Parameters

parameter	default
alpha	0.2
beta	0.2
tau	10.0

Usage

import tsdynamics as ts

sys = ts.ScrollDelay()
traj = sys.integrate(final_time=100.0, dt=0.01)
