WangSun

Systems · Continuous · Coupled systems

Dimension: 3

Equations

\[ \begin{aligned} \dot{y_{0}} &= a y_{0} + q y_{1} y_{2} \\ \dot{y_{1}} &= b y_{0} + d y_{1} - y_{0} y_{2} \\ \dot{y_{2}} &= e y_{2} + f y_{0} y_{1} \end{aligned} \]

Parameters

parameter	default
a	0.2
b	-0.01
d	-0.4
e	-1.0
f	-1.0
q	1.0

Usage

import tsdynamics as ts

sys = ts.WangSun()
traj = sys.integrate(final_time=100.0, dt=0.01)

Back to Coupled systems
