HyperXu

Systems · Continuous · Exotic systems

Dimension: 4

Equations

\[ \begin{aligned} \dot{y_{0}} &= - a y_{0} + a y_{1} + y_{3} \\ \dot{y_{1}} &= b y_{0} + e y_{0} y_{2} \\ \dot{y_{2}} &= - c y_{2} - y_{0} y_{1} \\ \dot{y_{3}} &= - d y_{1} + y_{0} y_{2} \end{aligned} \]

Parameters

parameter	default
a	10
b	40
c	2.5
d	2
e	16

Usage

import tsdynamics as ts

sys = ts.HyperXu()
traj = sys.integrate(final_time=100.0, dt=0.01)
