SanUmSrisuchinwong

Systems · Continuous · Coupled systems

Dimension: 3

Equations

\[ \begin{aligned} \dot{y_{0}} &= - y_{0} + y_{1} \\ \dot{y_{1}} &= - y_{2} \tanh{\left(y_{0} \right)} \\ \dot{y_{2}} &= - a + y_{0} y_{1} + \left|{y_{1}}\right| \end{aligned} \]

Parameters

parameter	default
a	2

Usage

import tsdynamics as ts

sys = ts.SanUmSrisuchinwong()
traj = sys.integrate(final_time=100.0, dt=0.01)
