DequanLi

Systems · Continuous · Coupled systems

Dimension: 3

Equations

\[ \begin{aligned} \dot{y_{0}} &= - a y_{0} + a y_{1} + d y_{0} y_{2} \\ \dot{y_{1}} &= f y_{1} + k y_{0} - y_{0} y_{2} \\ \dot{y_{2}} &= c y_{2} - eps y_{0}^{2} + y_{0} y_{1} \end{aligned} \]

Parameters

parameter	default
a	40
c	1.833
d	0.16
eps	0.65
f	20
k	55

Usage

import tsdynamics as ts

sys = ts.DequanLi()
traj = sys.integrate(final_time=100.0, dt=0.01)
