PiecewiseCircuit

Systems · Delay · Delayed systems

Dimension: 1

Equations

\[ \begin{aligned} \dot{y_{0}} &= - \alpha y_{0}{\left(t - \tau \right)} + \beta \left(\frac{3 y_{0}{\left(t - \tau \right)}}{c} - \frac{y_{0}^{3}{\left(t - \tau \right)}}{c^{3}}\right) \end{aligned} \]

Parameters

parameter	default
alpha	1.0
beta	1.0
c	2.24
tau	4.9

Usage

import tsdynamics as ts

sys = ts.PiecewiseCircuit()
traj = sys.integrate(final_time=100.0, dt=0.01)
