IkedaDelay

Systems · Delay · Delayed systems

Dimension: 1

Equations

\[ \begin{aligned} \dot{y_{0}} &= - c y_{0}{\left(t \right)} - \mu \sin{\left(x_{0} - y_{0}{\left(t - \tau \right)} \right)} \end{aligned} \]

Parameters

parameter	default
c	1.0
mu	-20
tau	2.0
x0	0.0

Usage

import tsdynamics as ts

sys = ts.IkedaDelay()
traj = sys.integrate(final_time=100.0, dt=0.01)
